TIDEACEBIKE
TT912 Aero Triathlon Time Trial Frames
Model: TT912 Disc
Frame Sizes: 47 / 49 / 52 / 54 / 56 / 58 cm
Material: High Modulus Toray T1000 Carbon Fiber
Fork: Integrated design, Flat Mount disc brake type
Head Tube: 1-1/8" (41.8mm) to 1-1/2" (52mm)
Bottom Bracket: BB386 Press-in
Weight: Frame 1650g ±50g (size 51cm), Fork 625g ±40g, Seatpost 210g ±20g
Stem: Adjustable length 85–100mm
Handlebar Width: 420mm
Seatpost Length: 400mm (for 74°–79° seat tube angle)
Spacer Heights: 5mm / 10mm / 20mm
Groupset Compatibility: Mechanical & Shimano Di2 electronic shifting compatible
Tire Size: 700×28C
Brake Type: Flat Mount disc brakes
Additional Features: Top Tube: PROFILE DESIGN Tool Box, Water Bottle Cage: Elite Carbon Bottle Cage
Key Features of Tideace Carbon TT Frame
The Tideace TT912 is a high-performance carbon Time Trial (TT) bike frame, engineered for serious triathletes and time trial racers who demand ultimate aerodynamic efficiency and power transfer. Built with premium T1000 carbon fiber, the TT912 combines ultra-lightweight stiffness, wind-cutting geometry, and integrated components for maximum speed on flat-out TT or triathlon courses.
Whether you're racing against the clock or chasing your personal best, the Tideace TT912 aero frame delivers unmatched performance, precision handling, and elite-level design.
Carbon Time Trial (TT) Bike Frame
Made from Toray T1000 carbon fiber, offering a perfect balance of strength, stiffness, and lightweight performance for time trials and triathlon races.
Aerodynamic Frame Geometry
Optimized aero tube shapes reduce drag and improve wind resistance. Tailored for flat-out speed, this time trial frame slices through the air with minimal turbulence.
UCI-Compliant Design
Frame geometry and tube profiles meet UCI regulations for Time Trial and Triathlon events, suitable for competitive racing worldwide.
Internal Cable Routing
Fully integrated internal cable routing enhances aerodynamic performance and maintains a clean, sleek aesthetic. Ideal for electronic (Di2) or mechanical groupsets.
UCI Legal TT Frame TT912
High-performance China Best triathlon bike carbon frame
FM-TT912 Geometry
Optimized aero tube shapes reduce drag and improve wind resistance. Tailored for flat-out speed, this time trial frame slices through the air with minimal turbulence.
Aerodynamic Frame Design
Aggressive aero tubing profile, including a deep downtube, integrated seat tube cutout, and tapered head tube for maximum airflow efficiency.
HEADSET
Its durable construction ensures that you'll enjoy a smooth and reliable riding experience for years to come, making it a sound investment for any serious cyclist.
Headset Size: 1-1/2 TO 1-1/8
Flexible tire compatibility
Road-smoothing super light carbon disc brake bicycle frame and clearance for up to 28C tires absorbs fatiguing bumps in the road for a smoother, more comfortable ride.
BB386 Bottom Bracket
BB386 bottom bracket standard ensures efficient power transfer with improved stiffness at the crank area.
Disc Brake Braking System
It is possible to install a 160mm rotor using the convension seat.
